  • Aten Kn2124Va 24 Port Cat5 1 Local 2 Uzak Kontrol PS/2 USB 2 Kvm Switch

    1-Local /2-Remote Access
    24-Port Cat 5 KVM over IP Switch with Virtual Media (1920 x 1200)

    • Exclusive KN Series Features
    • High-Grade Security – supports FIPS 140-2 level 1 security standards
    • Advanced FPGA graphics processor with Full HD resolutions up to 1920 x 1200
    • 2x faster virtual media transmission speeds
    • Simultaneously share one local console and two independent connections to servers
    • Hardware
    • High Port Density – RJ-45 connectors for up to 40 ports in 1U housing
    • Laptop USB Console (LUC) – a dedicated USB port directly connects to a laptop for easy console operation
    • Two separate buses for remote KVM over IP access
    • Two 10/100/1000 Mbps NICs for redundant LAN or dual IP operation
    • Blade server support
    • Supports PS/2, USB, Sun Legacy (13W3) and serial (RS-232) connectivity
    • Local console provides USB keyboard and mouse support
    • Supports multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices
    • Audio enabled
    • Dual Power Supply
    • High Video Resolutions – up to 1920 x 1200 @ 60 Hz with 24-bit color depth at the switch’s local console and on remote displays
    • Monitor and control up to 24 computers on a single level or control up to 384 computers in a cascade*
      *Cascade-compatible KVM switches include the following: CS9134, CS9138, KH1508A and KH1516A.
    • Management
    • Supports 64 user accounts – up to 32 users can simultaneously share control
    • Green IT Fan – speed varies according to temperature
    • Event logging and Windows-based Log Server support
    • Critical system event notification via SMTP email; SNMP trap and Syslog support
    • Customizable events notification
    • Firmware upgradeable
    • Adapter ID Function – stores port information, allowing administrators to relocate servers to different ports without having to re-configure adapters or switches
    • Port Share Mode – allows multiple users to gain access to a server simultaneously
    • Supported by ATEN's CC2000 Management Software
    • IPv6 capable
    • Easy-to-Use Interface
    • ATEN Exclusive Panel ArrayTM Mode – monitor all ports in a grid display of all desktops at both the local and remote screen
    • Multiplatform client support (Windows, Mac OS X, Linux, Sun)
    • Multi-browser support: Internet Explorer, Chrome, Firefox, Safari, Opera and Netscape
    • Browser-based UI in pure Web technology allows administrators to perform administrative tasks without pre-installed Java software
    • Launch multiple virtual remote desktop sessions to control multiple servers at the same time
    • Fullscreen or scalable virtual remote desktop window
    • Keyboard/Mouse Broadcast – keyboard and mouse signals can be duplicated across all servers at once
    • Video syncing with the local console – local console monitor’s EDID information stored on the KVM Adapter Cables for display resolution optimization
    • Advanced Security
    • Remote authentication support: RADIUS, LDAP, LDAPS and Microsoft Active Directory
    • Supports TLS 1.2 encryption and RSA 2048-bit certificates to secure browser logins
    • Flexible encryption design allows users to choose any combination of 56-bit DES, 168-bit 3DES, 256-bit AES, 128-bit RC4 or Random for independent Keyboard/Mouse, video and virtual media data encryption
    • Supports IP/MAC address filtering
    • Configurable user and group permissions for server access and control
    • Automated CSR creation utility and third-party CA certificate authentication
    • Virtual Media
    • Virtual media enables applications, OS patching, software installations and diagnostic testing
    • Works with USB-enabled servers at the operating system and BIOS level
    • Supports DVD/CD drives, USB mass storage devices, hard drives and ISO images
    • Virtual Remote Desktop
    • Video quality can be adjusted to optimize data transfer speeds; monochrome color depth, threshold and noise settings reduce data transmission to lower bandwidth
    • Fullscreen or scalable window for desktop sessions
    • Message Board for communication among remote users
    • Mouse DynaSync – automatically synchronizes the local and remote mouse movements
    • Exit Macro support
    • On-screen keyboard with multi-language support
    • BIOS-level access for troubleshooting



    Computer Connections
    Direct24
    Maximum384 (via Cascade KVM Switches)
    Console Connections
    Local1
    Remote2
    Port SelectionPushbuttons, Hotkeys, GUI
    Connectors
    Console Ports2 x USB Type A Female (White)
    1 x DVI-I Female (White)
    KVM Ports24 x RJ-45 Female (Black)
    USB Port3 x USB Female (White)
    Audio2 x Audio Jack Female (Pink; Green)
    Laptop USB Console (LUC) Port1 x Mini-USB Female (Black)
    LAN Ports2 x RJ-45 Female (Black)
    Power2 x IEC 60320/C14
    Switches
    Power2 x Rocker Switches
    Port Selection2 x Pushbuttons
    Reset1 x Semi-recessed Pushbutton
    LEDs
    Online / Selected24(Green/Orange)
    Power2 (Blue)
    Link 10 / 100 / 1000 Mbps2 (Red/Orange/Green)
    Emulation
    Keyboard / MousePS/2; USB
    Video
    Local1920 x 1200 @ 60Hz
    Remote1920 x 1200 @ 60Hz
    Maximum Input Power Rating100–240V~ ; 50-60Hz; 1A
    Power Consumption
    Single Power110V/32.78W; 220V/33.44W
    Dual Power110V/18.81W; 220V/19.36W (per input)
    Scan Interval1 – 255 Sec
    Environmental
    Operating Temperature0 - 40˚C
    Storage Temperature-20 - 60˚C
    Humidity0 - 80% RH, Non-condensing
    Physical Properties
    HousingMetal
    Weight5.48 kg ( 12.07 lb )
    Dimensions (L x W x H)43.36 x 41.21 x 4.40 cm
    (17.07 x 16.22 x 1.73 in.)
    • 1x KN2124VA KVM over IP Switch
    • 2x Power Cords
    • 1x Mounting Kit
    • 2x Lok-U-Plugs
    • 1x Lok-U-Plug Installation Tool
    • 1x Foot Pad Set (4 pcs.)
    • 1x User Instructions
    Diğer Özellikler
    Stok KoduATEN-KN2124VA
    MarkaATEN
    Stok DurumuVar
    Garanti (Yıl)2
    4719264644122
