Aten VE1821 40 Mt HDMI to RJ45 4K HDMI Mesafe Uzatıcı


  • Includes a transmitter and a receiver to work in tandem to extend 4K HDMI signals over a Cat 5e / 6 cable
  • Ultra lightweight, palm-sized enclosure for easy mounting or placement in tight spaces
  • Crystal clear 4K HDMI transmission with zero latency across up to 40 m via a Cat 6 cable (ATEN 2L-2910 recommended) /30 m via a Cat 5e cable
  • Local HDMI output port on the transmitter unit – enables cascading or users to monitor the UHD signal being extended to the receiver
  • Built-in EDID switch – users can control which EDID is taken from either display
  • EDID Copying Mode – HDMI source can be displayed at the optimal resolution based on the capabilities of the connected display
  • IR signal transmission – the source device connected to the transmitter can be seamlessly controlled from the receiver side
  • PoC (Power over Cable) technology – power can be delivered from the transmitter to the receiver via a Cat 5e / 6 cable to eliminate the need for a bulky external power supply
  • HDMI (3D, Deep Color, 4K); HDCP 1.4 compliant
  • Built- in ESD protection
  • Plug-and-play – no additional software needed






Input Resolutions 640x480 @ 60/75 Hz 1920x1080 @ 60 Hz
800x600 @ 60/75 Hz 1920x1200 @ 60 Hz
1024x768 @ 60/75 Hz 480p @ 60 Hz (4:3)/(16:9)
1280x800 @ 60 Hz 576p @ 50 Hz (4:3)
1280x1024 @ 60/75 Hz 640x480 @ 60Hz (4:3)
1400x1050 @ 60 Hz 720p @ 50/60 Hz
1440x900 @ 60 Hz 1080p @ 24/25/30/50/60 Hz
1600x1200 @ 60 Hz 3840x2160p @ 24/25/30 Hz
1680x1050 @ 60 Hz 4096x2160p @ 24/25/30 Hz
Function VE1821R VE1821T
Video Input
Interfaces N/A 1 x HDMI Type A Female (Black)
Impedance N/A 100 Ω
Max. Distance N/A 3 m
Video Output
Interfaces 1 x HDMI Type A Female (Black) 1 x HDMI Type A Female (Black)
Impedance 100 Ω 100 Ω
Max. Distance 3 m 3 m
Video
Max. Data Rate 10.2Gbps (3.4Gbps per lane) 10.2Gbps (3.4Gbps per lane)
Max. Pixel Clock 340 MHz 340 MHz
Compliance HDMI (3D, Deep Color, 4K)
HDCP1.4 Compatible		 HDMI (3D, Deep Color, 4K)
HDCP1.4 Compatible
Max. Resolutions / Distance Up to 4K@30m (Cat5e), 40m (Cat 6/ATEN 2L-2910);

*4K supported:
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)		 Up to 4K@30m (Cat5e), 40m (Cat 6/ATEN 2L-2910);

*4K supported:
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio
Input N/A 1 x HDMI Type A Female (Black)
Output 1 x HDMI Type A Female (Black) N/A
Control
IR Channel 1 x Mini Stereo Jack Female (Black);
Single way bypass channel from receiver to transmitter		 1 x Mini Stereo Jack Female (Black);
Single way bypass channel from receiver to transmitter
Switches
Mode Switch N/A EDID Mode Selection (Read EDID from Transmitter HDMI output or Receiver HDMI output)
Connectors
Power 1 x RJ-45 Female
(Power over Cable, power supply from VE1821T)		 1 x DC Jack (Black) with locking
Unit To Unit 1 x RJ-45 Female 1 x RJ-45 Female
Power Consumption POC:0.87W:4BTU DC12V:1.86W:9BTU
Environmental
Operating Temperature 0 - 40°C 0 - 40°C
Storage Temperature -20 - 60°C -20 - 60°C
Humidity 20 - 90% RH, Non-Condensing 20 - 90% RH, Non-Condensing
Physical Properties
Housing Metal Metal
Weight 0.12 kg ( 0.28 lb ) 0.12 kg ( 0.28 lb )
Dimensions (L x W x H) with bracket 7.95 x 6.80 x 1.65 cm
(3.13 x 2.68 x 0.65 in.)		 7.95 x 6.80 x 1.65 cm
(3.13 x 2.68 x 0.65 in.)
Dimensions (L x W x H) without bracket 5.75 x 6.80 x 1.65 cm (2.26 x 2.68 x 0.65 in.) 5.75 x 6.80 x 1.65 cm (2.26 x 2.68 x 0.65 in.)



  • 1x VE1821T 4K HDMI Cat 6 Extender (Transmitter)
  • 1x VE1821R 4K HDMI Cat 6 Extender (Receiver)
  • 1x IR emitter cable
  • 1x IR receiver cable
  • 1x power adapter and 4 power plugs
  • 1x user instructions

Diğer Özellikler
Stok KoduATEN-VE1821
MarkaATEN
Stok DurumuVar
Garanti (Yıl)2
4710469342790
