Intel Core i7-12700, 12C (8P + 4E) / 20T, P-core 2.1 / 4.8GHz, E-core 1.6 / 3.6GHz, 25MB

1x FCLGA1700

Intel UHD Graphics 770

1x NVIDIA RTX A2000 12GB

Intel W680

1x 16GB UDIMM DDR5-4400 ECC

Four DDR5 UDIMM slots, dual-channel capable

Up to 128GB DDR5-3600

Onboard Intel RSTe PCIe

1TB SSD M.2 2280 PCIe Gen 4x4 Performance NVMe Opal

Onboard Intel RST SATA RAID

None

Up to 2x 3.5" SATA HDD or 4x 2.5" SATA HDD; also supports up to 3x M.2 SSD (2 by onboard, 1 by M.2 to PCIe adapter ) • 3.5" HDD up to 4TB each • 2.5" HDD up to 1TB each • Onboard M.2 SSD up to 4TB each • M.2 SSD by M.2 to PCIe adapter up to 2TB

None

High Definition (HD) Audio, Realtek ALC897Q-CG codec

750W Platinum Fixed

USB Traditional Keyboard, Black, Turkish

USB Calliope Mouse, Black

• One PCIe 4.0 x16
• One PCIe 4.0 x16 (x4 lanes)
• Two PCIe 3.0 x1 (open ended)

• Up to 3x M.2 SSD: • 2 via onboard M.2 PCIe Gen 4 slots • 1 via Single M.2 to PCIe adapter, PCIe Gen 3
• One M.2 slot for WiFi

• 1x 3.5" disk bay (standard)
• 2x 2.5" disk bay (optional)
• 1x 3.5" disk bay (optional)

170 x 315.4 x 376 mm (6.7 x 12.4 x 14.8 inches)

9.67 kg (21.32 lbs, maximum configuration)

Intel I219-LM, 1x GbE RJ-45

None

None

SD Card Reader

• 2x USB 3.2 Gen 1
• 2x USB 3.2 Gen 2
• 1x USB-C 3.2 Gen 2
• 1x headphone / microphone combo jack (3.5mm)
• 1x microphone (3.5mm)

• 4x USB 3.2 Gen 1 (one supports Smart Power On)
• 1x HDMI 2.1 TMDS
• 2x DisplayPort 1.4
• 1x Ethernet (RJ-45)
• 1x line-out (3.5mm)

None
