Lindy LIN-43314 USB Typec 3.2 to RJ45 2.5G Ethernet Dönüşütrücü

Technical details

Specifications

• Interface: USB to RJ45
• Interface Standard: USB 3.2 / 3.1 Gen 1 / 3.0, 2.5G LAN
• Supported Bandwidth: 5 Gbps (USB), 10/100/1000Mbps/2.5Gbps
• Chipset: RTL8156B
• Compatibility: USB Type C equipped computers, Windows, Mac (including Apple M based processors) & Linux OS
• Power Delivery: -
• Special Features: Supports Wake on LAN (WoL)

Connectors

• Inputs: 1 x USB Type C (Male)
• Outputs: 1 x RJ45 (Female)
• Power:
  • Standby Power< 80mA (when Ethernet cable is not connected)
  • Normal Operating Power:
    • < 80mA  10Mbps
    • < 130mA 100Mbps
    • < 300mA 1Gbps
    • < 460mA 2.5Gbps

Physical Properties

• Dimensions WxDxH:  60x22x17mm (2.36x0.87x0.67in)
• (Fixed) Cable Length: 270mm (10.63in)
• Housing Material: Aluminium
• Net Weight: 0.034kg (0.07lb)
• Operating Temperature: 0° to 70° C (32°F _ 158°F)
• Storage Temperature: -20° to 70° C (-4°F _ 158°F)
• Humidity: 5 - 95% RH (non-condensing)
• Power Requirements: <450mA @5V
• Colour: Silver

Miscellaneous

• Packaging Type: Polybag
• Packaging Dimensions: 133x144mm (5.24x5.67in)
• Gross Weight: 0.38kg (0.08lb)
• Warranty (Years): 2
• Product Compliance: CE, FCC, RoHS & REACH, POP, CP65

Package content

• USB 3.2 Type C to 2.5G Ethernet Converter
