Planet PL-GS-4210-8HP2S 2 Port 1000T PoE 6 Port 100T 2 Port SFP Managed Switch
ParaPuan : 5.255.980
| Fiyat | : | 12.614,36 TL |
Planet PL-GS-4210-8HP2S 2 Port 1000T PoE 6 Port 100T 2 Port SFP Managed Switch
| Hardware Specifications | |
|---|---|
| Copper Ports | 8 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port |
| SFP Slots | 2 x 100/1000BASE-X SFP interface Supports 100/1000Mbps dual mode and DDM |
| PoE Injector Port | 6 ports with 802.3at PoE+ injector function (Ports 1 to 6) 2 ports with 802.3bt PoE++ injector function (Ports 7 to 8) |
| Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
| LED Indicators | PWR, LNK/ACT, PoE-in-Use, LED Mode |
| Power Requirements | 100~240V AC, 50/60Hz, auto-sensing |
| Dimensions (W x D x H) | 280 x 229 x 44 mm, 1U height |
| ESD Protection | Contact Discharge 6KV DC Air Discharge 8KV DC |
| Enclosure | Metal |
| Weight | 1920g |
| Power Consumption/Dissipation | 280 watts (max.)/2013.2 BTU |
| Fan | 1 x smart fan Supports fanless mode |
| Switch Specifications | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 20Gbps/non-blocking |
| Switch Throughput@64Bytes | 14.88Mpps |
| Address Table | 8K entries |
| Shared Data Buffer | 4.1 megabits |
| Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
| Jumbo Frame | 10K bytes |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3af/at PoE+ PSE (Ports 1 to 6) IEEE 802.3bt PoE++ PSE (Ports 7 to 8) |
| PoE Power Supply Type | End-span (Ports 1 to 6) End-span/Mid-span/802.3bt (Ports 7 to 8) |
| PoE Power Output | Ports 1 to 6: Per PoE+ port 54V DC, max. 30 watts Ports 7 to 8: 802.3bt mode, maximum 95 watts End-span mode: maximum 30 watts Mid-span mode: maximum 30 watts |
| Power Pin Assignment | End-span: 1/2 (-), 3/6 (+) Mid-span: 4/5 (+), 7/8 (-) 802.3bt: 1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-) |
| PoE Power Budget | 240 watts with standard mode 100 watts with fanless mode |
| PoE Ability PD @ 12.5 watts | 8 units with standard mode 8 units with fanless mode |
| PoE Ability PD @ 25 watts | 8 units with standard mode 4 units with fanless mode |
| PoE Ability PD @ 51 watts | 2 units with standard mode 1 units with fanless mode |
| PoE Ability PD @ 71 watts | 2 units with standard mode 1 units with fanless mode |
| PoE Management Functions | |
| Active PoE Device Detection | Yes |
| PoE Power Recycling | Yes, daily or predefined schedule |
| PoE Schedule | 4 schedule profiles |
| PoE Extend Mode | Yes, max. up to 250 meters |
| PoE Port Management | Port Enable/Disable/Schedule PoE mode control ?802.3bt ?802.3at End-span ?802.3at Mid-span Port Priority |
| Layer 2 Functions | |
| Port Mirroring | TX/RX/both Many-to-1 monitor Up to 4 sessions |
| VLAN | 802.1Q tag-based VLAN Up to 256 VLAN groups, out of 4094 VLAN IDs 802.1ad Q-in-Q tunneling Voice VLAN Protocol VLAN Private VLAN (Protected port) GVRP |
| Link Aggregation | IEEE 802.3ad LACP and static trunk Supports 2 groups of 2-port trunk |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping | IGMP (v2/v3) snooping IGMP querier Up to 256 multicast groups |
| MLD Snooping | MLD (v1/v2) snooping, up to 256 multicast groups |
| QoS | 8 mapping IDs to 8 level priority queues ?Port number ?802.1p priority ?802.1Q VLAN tag ?DSCP field in IP packet Traffic classification based, strict priority and WRR |
| Ring | Supports ERPS, and complies with ITU-T G.8032 |
| Security Functions | |
| Access Control List | IPv4/IPv6 IP-based ACL/MAC-based ACL |
| Port Security | IEEE 802.1X – Port-based authentication Built-in RADIUS client to co-operate with RADIUS server RADIUS/TACACS+ user access authentication |
| MAC Security | IP-MAC port binding MAC filter Static MAC address |
| Enhanced Security | DHCP Snooping and DHCP Option82 STP BPDU guard, BPDU filtering and BPDU forwarding DoS attack prevention ARP inspection IP source guard |
| Management Functions | |
| Basic Management Interfaces | Web browser; Telnet; SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLS v1.2, SNMP v3 |
| System Management | Firmware upgrade by HTTP/TFTP protocol through Ethernet network LLDP protocol SNTP PLANET Smart Discovery Utility PLANET NMS System and CloudViewer app |
| Event Management | Remote/Local Syslog System log |
| Teknik Özellikler | |
|---|---|
| Kullanım Tipi | PoE Switch |
| Port Sayısı | 8 Port |
| Veri Transferi | 1 Gigabit |
| Yönetim | Var |
| Ethernet Port | 5 Port |
| SFP Port | 2 Port |
| PoE Port | 2 Port |
| Diğer Özellikler | |
|---|---|
| Stok Kodu | PL-GS-4210-8HP2S |
| Marka | PLANET |
| Stok Durumu | Var |
| Garanti (Yıl) | 2 |
