    • Planet PL-IFT-805AT 10/100Base-TX to 10BAse-FX Industrial Media Converter

      Görsel 1
      ParaPuan : 700.875
      Fiyat:
      1.654,07 TL
      149,56 TL'den başlayan taksit seçenekleri için tıklayın.
      Aynı Gün Kargo Sınırlı Sayıda
      10/100Base-TX to 100Base-FX (SFP) Industrial Media Converter
      (-40~75 degrees C)


      Interface
      • 1-port 10/100Base-T RJ-45 with auto negotiation and auto-MDI/MDI-X function
      • 1 100Base-FX SC interface, providing long distance up to 2km on IFT-802T
      • 1 100Base-FX SC interface, providing long distance for 15km on IFT-802TS15
      • 1 Mini-GBIC slot, providing multi choice of SFP modules on IFT-805AT

      Industrial Conformance
      • 12V to 48V DC, redundant power with polarity reverse protect function
      • -40 to 75 degrees C operating temperature
      • IP30 metal case
      • Relay alarm for port breakdown
      • Supports 6KV DC Ethernet ESD protection
      • Supports 6KV DC EFT protection for power line
      • Free Fall, Shock and Vibration Stability
      • DIN-rail and wall-mountable hardware design

      Layer 2 Features
      • Complies with the IEEE 802.3, IEEE 802.3u Fast Ethernet standard
      • Auto-MDI / MDI-X detection and auto negotiation in half-duplex / full-duplex modes for 10 /100Base-TX RJ-45 port
      • Store-and-Forward Switching Architecture
      • Features Store-and-Forward mode with wire-speed filtering and forwarding rates
      • Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
      • Supports packet size of up to 1522bytes
      • CSMA/CD Protocol
      • Automatic source address learning and aging



      Hardware Specifications
      10/100Base-TX Port1 RJ-45 auto-MDI / MDI-X port
      100Base-FX PortIFT-802T: 1 SC interface
      IFT-802TS15: 1 SC interface
      IFT-805AT: 1 SFP slot
      Fiber Port TypeIFT-802T: SC / multi-mode
      IFT-802TS15: SC / single-mode
      IFT-805AT: Vary on module
      Cable DistanceIFT-802T: 2km
      IFT-802TS15: 15km
      IFT-805AT: Vary on module
      Optical FrequencyIFT-802T: 1310nm
      IFT-802TS15: 1310nm
      IFT-805AT: Vary on module
      Launch Power (dBm)Max
      IFT-802T: -14
      IFT-802TS15: 0

      Min
      IFT-802T: -20
      IFT-802TS15: -20

      Vary on module
      IFT-805AT
      Receive Sensitivity (dBm)IFT-802T: -32
      IFT-802TS15: -32
      IFT-805AT: Vary on module
      Maximum Input Power (dBm)IFT-802T: -14
      IFT-802TS15: 0
      IFT-805AT: Vary on module
      Dimensions (W x D x H)135 x 85 x 32 mm
      Weight430g
      InstallationDIN rail kit and wall mount ear
      Maximum Frame Size1522bytes packet size
      Flow ControlBack pressure for half duplex, IEEE 802.3x pause frame for full duplex
      EnclosureIP-30 slim type metal case
      LED IndicatorSystem:
       •Power 1 (Green)
       •Power 2 (Green)
       •Fault (Green)
      1 x copper port:
       •10/100 (Green)
       •LNK/ACT (Green)
      1 x 100FX port:
       •100 (Green)
       •LNK/ACT (Green)
      Power Input12 to 48V DC redundant power with polarity reverse protection function
      Power Consumption3 watts/ 10BTU (maximum)
      ProtectionESD (Ethernet): 6KV DC
      Surge (Power): 6KV DC
      SpeedTwisted-pair:
       •10/20Mbps for half / full-duplex
       •100/200Mbps for half / full duplex
      Fiber-optic:
       •200Mbps for full-duplex
      Network cables10/100Base-TX:
       •2-pair UTP Cat. 3, 4, 5 (100 meters, max.)
       •EIA/TIA-568 100-ohm STP (100 meters, max.)
      100Base-FX:
       •IFT-802T: Multi-mode optical fiber 62.5/125μm / 50/125μm (2km)
       •IFT-802TS15: Single-mode optical fiber 9/125μm (15km)
       •IFT-805AT: SFP slot (depending on SFP module)
      Standards Conformance
      EmissionsFCC Class A, CE Class A
      Standards ComplianceIEEE 802.3 10Base-T
      IEEE 802.3u 100Base-TX / 100Base-FX
      IEEE 802.3x flow control and back pressure
      Stability TestingIEC60068-2-32 (Free Fall)
      IEC60068-2-27 (Shock)
      IEC60068-2-6 (Vibration)
      Environment
      Operating Temperature-40~75 degrees C
      Operating Humidity5~95% non-condensing
      Storage Temperature-40~85 degrees C
      Storage Humidity5~95% non-condensing
      Diğer Özellikler
      Stok KoduPL-IFT-805AT
      MarkaPLANET
      Stok DurumuVar
      Garanti (Yıl)2
