Planet PL-POE-171 10/100/1000Mbps 60W Ultra PoE Sigle Port Injector
ParaPuan : 1.203.840
1
Single-Port 10/100/1000Mbps Ultra PoE Injector (60 Watt)
nterface
- - 1-Port Data + Power output
- - 1-Port Data input
- 2-Port RJ-45 interface
- 1 DC 52~56V input power socket
Power over Ethernet
- Ultra Power over Ethernet End-Span/Mid-Span PSE
- IEEE 802.3at/af PoE standard compliant
- Compatible with All IEEE 802.3at/af powered devices
- Supports 56VDC, 60-watt PoE power output at maximum
- Auto-detection of PoE IEEE 802.3at/af equipment and device for possible damage by incorrect installation
- Automatic detection and protection of non–standard Ethernet terminals
- Remote power feeding up to 100 meters
Hardware
- Compact size metal case
- LED indicators for power LED and PoE In-use LED
Standard Compliance
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3at High Power over Ethernet
- IEEE 802.3af Power over Ethernet
- FCC Part 15 Class A, CE
| Hardware Specifications | |
| Interface | Input Port ?? 1 x RJ-45 STP ?? Data In Output Port ?? 1 x RJ-45 STP ?? PoE (Data + Power) Out DC socket ?? 56V DC Input |
| LED Indicator | System: Power x 1 (Green) PoE Port: PoE in Use x 1 (Green) |
| Network Cable | Ultra PoE (60W): ?10/100/1000Base-T: 4-Pair UTP Cat. 5e, 6 up to 100m (328ft) 802.3af / at PoE(15W / 30W): ?10/100/1000Base-T: 2-Pair UTP Cat. 3, 5, 5e, 6 up to 100m (328ft) |
| Data Rate | 10/100/1000Mbps |
| Dimensions (W x D x H) | 95 x 70 x 26 mm |
| Weight | 237g |
| Unit Input Voltage | DC 56V |
| Power Requirements | External AC-to-DC adapter 100-240V AC, 50/60Hz, 1.5A |
| Power Consumption | 60 watts max. |
| Operating Temperature | 0 ~ 50 degrees C |
| Storage Temperature | -10 ~ 70 degrees C |
| Operating Humidity | 5 ~ 90%, Relative Humidity, non-condensing |
| Storage Humidity | 5 ~ 90%, Relative Humidity, non-condensing |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3at High Power over Ethernet End-span / Mid-span PSE |
| Power Output | DC 56V / 60-watt PoE via 4-pairs DC 56V / 30-watt PoE via 2-pairs |
| PoE Power Supply Type | End-Span + Mid-Span |
| Power Pin Assignment | Pair 1: 1/2(-), 3/6(+) Pair 2: 4/5(+), 7/8(-) |
| Standards Conformance | |
| Standards Compliance | IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3at High Power over Ethernet IEEE 802.3af Power over Ethernet |
| Regulation Compliance | FCC Part 15 Class A, CE |
| Diğer Özellikler | |
|---|---|
| Stok Kodu | PL-POE-171 |
| Marka | PLANET |
| Stok Durumu | Var |
| Garanti (Yıl) | 2 |
