Teltonika TE-TSW101 5 Port Gigabit 4 Port PoE+ Aouromotive PoE+ Switch


INTERFACES
Ethernet 5 x RJ45 ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
POE
PoE ports Port 1- 4
PoE standards 802.3af and 802.3at
PoE Max Power per Port (at PSE) 30 W
Total PoE Power Budget (at PSE) 60 W
Maximum Ethernet cable length 100 m
PERFORMANCE SPECIFICATIONS
Bandwidth (Non-blocking) 10 Gbps
Packet buffer 128 KB
MAC address table size 2K entries
Jumbo frame support 9216 bytes
POWER
Connector 2-pin industrial DC power socket
Input voltage range 9-30 VDC
Input voltage range for PoE 9-30 VDC
Power consumption Idle: 0.64 W / Max: 2.31 W / PoE Max: 60 W
PHYSICAL INTERFACES (PORTS, LEDS)
Ethernet 5 x RJ45 ports, 10/100/1000 Mbps
Status LED’s 1 x Power LED, 10 x LAN status LED’s
Power 1 x 2-pin industrial DC power socket
Ground 1 x Grounding screw
PHYSICAL SPECIFICATION
Casing material Aluminum housing
Dimensions (W x H x D) 115 x 32 x 95 mm
Weight 354 g
Mounting DIN rail or wall mounting (additional kit needed), flat surface placement
OPERATING ENVIRONMENT
Operating temperature -40 °C to +75 °C
Operating humidity 10 % to 90 % non condensing
Ingress Protection Rating IP30
CERTIFICATION & APPROVALS
Regulatory CE, REACH, RoHS, WEEE
  TSW101 CE
  TSW101 UKCA
  TSW101 FCC
  TSW101 IC
  TSW101 CB
  TSW101 RCM
  E-Mark

Kıyaslama Listene Ekle
Teknik Özellikler
Kullanım TipiPoE Switch
Port Sayısı5 Port
Veri Transferi1 Gigabit
YönetimYok
Ethernet Port1 Port
SFP PortYok
PoE Port4 Port
Diğer Özellikler
Stok KoduTE-TSW101
MarkaTELTONIKA
Stok DurumuVar
Garanti (Yıl)2
4779051840113
